Universal Black Aluminum Electric Inline EFI Fuel Pump, Filter, & Bracket

Take care of your fuel delivery needs with this two-in-one electric fuel pump and filter kit. This kit features a high-flow pump, efficient filter, and an easy to mount bracket.

TSP's high-flow, electric fuel pump is a great fuel delivery solution for your EFI power plant. Housed in the "044" style, it comes with all fittings and post hardware for simple installation. Compatible with EFI gasoline applications, it flows at 320 liters, or 85 gallons, per hour.

Precision-machined from 6061-T6 billet aluminum, TSP's inline fuel filters offer simple, reliable filtration and versatility. They are designed for maximum flow, with almost no pressure drop, and can be used in fuel injected or carbureted engines with low or high horsepower.

CNC-machined from lightweight billet aluminum, TSP's fuel pump and filter mounting bracket is a simple tool to help when configuring your fuel system. It utilizes a straight-forward clamp design for easy installation, and it's diameters are designed for the Bosch 044 style fuel pump (TSP JM1040) and inline fuel filter (TSP JM1021, JM1022, JM1023).

PUMP FREE FLOW 320 lph (85 gph)
MAXIMUM PRESSURE 90 PSI
HOUSING MATERIAL Aluminum
INLET ATTACHMENT Female
INLET SIZE -10 AN
INLET QUANTITY One
OUTLET ATTACHMENT Female
OUTLET SIZE -6 AN
OUTLET QUANTITY One
INCLUDED (1) -6 AN to -8 AN Fitting
(1) -10 AN to -8 AN Fitting
(1) -6 AN to -8 AN Fitting
(2) Push Lock 180° -8 AN Fittings
(2) Push Lock 90° -8 AN Fittings
(2) Electrical Ring Terminals
(2) Terminal Post Nuts & Washers
(2) Terminal Post Boots

FILTER TYPE Inline
INLET SIZE -10 AN O-Ring
INLET ATTACHMENT Female
OUTLET SIZE -10 AN O-Ring
OUTLET ATTACHMENT Female
SMALLEST PARTICLE FILTERED 10 Microns
MAXIMUM FUEL PRESSURE 250 PSI
ELEMENT MATERIAL Paper
HOUSING MATERIAL Aluminum
HOUSING LENGTH 5.5" (140mm)
HOUSING DIAMETER 2" (50mm)
CLAMPS Not Included
MOUNT Not Included
FITTINGS Not Included

BRACKET STYLE Clamp
BRACKET MATERIAL Billet Aluminum
INSERT MATERIAL Silicone
PUMP DIAMETER 60mm with Insert
FILTER DIAMETER 50mm with Insert
HARDWARE Not Included

THIS PRODUCT IS UNIVERSAL
Pump requires the use of 100 micron pre-filter
Filter can be configured as pre-filter or post-filter
